Description of the 3DOF Platform
3DOF Platform
Motion platform 2DOF allows you to experience linear acceleration and Roll- Pitch. Active Game produces the most dynamic 2DOf platforms available in varying capacities.
3DOF Platform
3DOF Platform 300
-
Nominal Load - 300 kg. - Motions Range (Pitch, Roll) - 45 °.
- Heave – 240mm.
- Motion Speed - up 250mm/s² , to 180°/s²
- Power consumption: Single-phase, 220 V, 3.3 kW.
- Weight - 250 kg.
- Size: Width-100сm. Length - 100сm. Height - 80сm.
3DOF Platform
3DOF Platform 1000
- Nominal Load - 1000 kg.
- Motions Range (Pitch, Roll) - 54°.
- Heave – 240mm.
- Motion Speed - up 250mm/s² , to 180°/s²
- Power consumption: Single-phase, 220 V, 5 kW.
- Weight - 500 kg.
- Size: Width-120сm. Length - 120сm. Height - 100сm.
3DOF Platform
3DOF Platform 2000
- Nominal Load - 2000 kg.
- Motions Range (Pitch, Roll) - 50°.
- Heave – 240mm.
- Motion Speed - up 250mm/s² , to 180°/s²
- Power consumption: Three-phase, 380 V, 9.9 kW.
- Weight - 950 kg.
- Size: Width-160сm. Length - 160сm. Height - 120сm.
